Caterpillar Excavator 320E
Create an account to install this asset package.
Maintenance Plans for Caterpillar Excavator Model 320E
Integrate maintenance plans directly into your work orders in MaintainX.
Heating and Air Conditioning Assembly
Fan and Harness Installation
Ensure the following parts are installed
Connect harness assembly (9) to blower control
Evaporator and Cover Installation
Ensure the following parts are installed
Core and Actuator Installation
Ensure the following parts are installed
Connect harness assemblies (5)
Final Actuator and Harness Installation
Refrigerant Receiver-Dryer Removal and Installation
Safety Precautions
Wear protective goggles when opening refrigerant lines
Ensure no smoking in the vicinity of refrigerant gas
Use a certified recovery and recycling cart for refrigerant removal
Removal Procedure
Recover the air conditioner refrigerant from the system
Open the left side access door
Disconnect lines from the refrigerant dryer
Remove clamps and refrigerant dryer
Heating and Air Conditioning Disassembly
Pre-disassembly cleaning
Clean the exterior of the component thoroughly
Disassemble harness assembly and actuator motor
Disconnect harness assembly (1)
Remove actuator motor (2)
Remove cover and core
Remove cover (3)
Disconnect harness assemblies (5)
Remove actuator motors (4)
Control Module Automatic Temperature Control Unit Removal and Installation
Removal Procedure
Remove covers and screws
Remove screws from control panel (4)
Disconnect harness assemblies
Disconnect additional harness assemblies
Disconnect antenna and remaining harness assemblies
Remove control module (4)
Installation Procedure
Install control panel (4) in the reverse order of the removal
Heating and Air Conditioning Removal and Installation
Safety Precautions
Wear protective goggles when opening refrigerant lines
Ensure no smoking near refrigerant gas
Refrigerant Handling
Use certified recovery and recycling cart to remove refrigerant
Refer to Service Manual SENR5664 for recovery and charging procedure
Removal Procedure
Disconnect hose assembly (3) and remove switch (2) and bolts (1)
Clamp and remove hoses (4) to contain coolant
Parts for Caterpillar Excavator 320E
Access the parts list for your equipment in MaintainX.
DuoCone Seal Gp
8E-5608
O-Ring Seal
6V-7661
Hydraulic Jack
8T-5255
O-Ring Seal
7F-8268
Duo-Cone Seal Gp
9W-2142
DuoCone Seal Gp
8E-5608
O-Ring Seal
6V-7661
Hydraulic Jack
8T-5255
O-Ring Seal
7F-8268
Duo-Cone Seal Gp
9W-2142
DuoCone Seal Gp
8E-5608
O-Ring Seal
6V-7661
Hydraulic Jack
8T-5255
O-Ring Seal
7F-8268
Duo-Cone Seal Gp
9W-2142
