Genie Articulated Boom Lift S-60 TraX

Air cleaner element maintenance

Valve and Air System Inspection

Test the Drive Speed - Stowed Position

Ensure the machine is on a firm, level surface free of obstructions

Ensure the machine is in the stowed position

Mark start and finish lines 40 feet / 12.2 m apart

Choose a reference point on the machine for timing

Bring the machine to top drive speed before the start line

Record the time when the reference point crosses the start line

Record the time when the reference point crosses the finish line

Refer to Specifications, Drive Speed Specifications for results

- Inspect the Boom Extend/Retract Cables

Manufacturers specifications require that this procedure be performed by personnel that are competent in cable / wire rope inspection

Note: Additional or more frequent inspections may be required due to the following:

• exposed to hostile or corrosive environmental conditions

The boom extend/retract cables are responsible for the extension and retraction of the boom tubes

Check the Generator Belts, Pulleys and Voltage - Bi-Energy Models

Ensure the engine is not running and the key is removed

Be cautious of hot engine components to avoid burns

Ensure all fasteners and cables on the generator are tight

Remove the engine flywheel cover mounting fasteners
