Still Pallet Electric Forklift CX-20

CAUTION! If water penetrates the electrical system, there is a risk of a short circuit occurring

Never clean the components used for ASSISTANCE mode using devices such as high-pressure cleaners or rotating brushes

While cleaning the rest of the truck, avoid cleaning the components used for ASSISTANCE mode and only clean these components in accordance with the instructions specified below

CAUTION! Risk from damage to electrical components when cleaning! Only the authorised service centre is permitted to clean the components used for ASSISTANCE mode inside the truck

Contact the authorised service centre

CAUTION! Risk of component damage! If you remove the battery male connector when the key switch is switched on (under load), an arc will be produced. This can lead to erosion at the contacts, which considerably shortens their service life

Switch off the key switch before the battery male connector is disconnected

Do not disconnect the battery male connector while the key switch is switched on, except in an emergency

Check the safety laser scanner and the support mounting for damage (visual inspection)

Check the alignment and the field of vision of the SICK safety laser scanner using the SICK CDS software

Clean the optical cover of the safety laser scanner

Check the function of the personal protection system

Check the function of the emergency off switch and the safety laser scanner S300 in ASSISTANCE mode

Check the emergency off switching signal in DIAMON

Check the movement tracking sensors and the mounting for damage (visual inspection)

Check the plug contacts (power supply and communications supply)

Check the status LEDs for the movement tracking sensors (visual inspection)

Clean the movement tracking sensors

Sign off on the sensor maintenance

Check the clearance of the electromagnetic brake (in accordance with the maintenance manual for the series-production truck)

Read out and check the error numbers and clear the list
