Kubota Tractor B6100HST

The implement lifting and lowering limits can be changed by shifting the locker (A) or (B).

- Lower Limit: The lower limit can be changed by shifting the fixing position of the locker (A). Shifting the locker (A) backward lowers the limit and shifting it forward raises the limit.

- Upper Limit: The upper limit can be changed by shifting the fixing position of the locker (B). Shifting the locker (BI backward lowers the upper limit and shifting it forward raises the limit.;

SAFETY PRECAUTION: Never take off the cap while the engine is running. Keep electrolyte away from eyes, hands and clothes. If you are spattered with it, wash it away completely with water.

CAUTIONS: When connecting the battery, do not reverse the polarities. Connection with reverse polarities causes troubles to the battery and electrical system in the tractor.

Disconnect the cord from the battery, starting with the negative terminal first.

When connecting, start with the positive terminal first. Reversing the steps may cause short circuiting, should a screwdriver touch the terminals.

To prevent trouble from occurring, it is important to know the conditions of the tractor well. Check it before starting.

[SAFETY PRECAUTION]: Be sure to check and service the tractor on a flat place with the engine shut off and the parking brake on.

1) Check the parts where there was trouble before.

(1) Check the tire pressure, and check for wear and damage. (See page 45)

(2) Check for oil and water leaks.

(3) Check the engine oil level and check for contamination. (See page 35)

(4) Check the amount of transmission oil and whether it is contaminated. (See page 37)

(5) Check if there is enough fuel. (See page 31)

Warning: Ensure the engine is off before starting the procedure

If fan drive belt is loose, follow the steps below

Loosen the adjusting nut and tighten the tension bolt to stretch the belt

Adjusting nut tightened after adjustment?

If dynamo drive belt is loose, follow the steps below

Loosen the bolts and turn the dynamo to stretch the belt

Three bolts tightened after adjustment?

(1) After the initial 50 hours of use, change the transmission oil and the oil filter cartridge and clean the strainers.

(2) Sudden starting or braking should be avoided.

[SAFETY PRECAUTION]: Be sure to stop the engine before changing the oil filters.

(1) The oil filter cartridge must be changed every 200 service hours.

(2) Remove the 4 bolts which secure the cover. Detach the knob of the speed set device to remove the cover.

(3) Remove the oil filter cartridge by using the filter wrench.

(4) Lightly tighten the screw ~A by using a screwdriver.

(5) Apply a slight coat of oil onto the cartridge gasket.

(6) To install the new cartridge, screw it in by hand. Over tightening may cause deformation of rubber gasket.
