Kubota Tractor L5030

CAUTION! Before changing oil, be sure to stop the engine. Allow engine to cool down sufficiently, oil can be hot and can burn.

Start and warm up the engine for approx. 5 minutes

Place an oil pan underneath the engine

To drain the used oil, remove the both drain plugs (1) at the bottom of the engine and drain the oil completely

Screw in the both drain plugs (1)

Fill new oil up to upper line on the dipstick (2)

IMPORTANT: When using an oil of different manufacture or viscosity from the previous one, remove all of the old oil. Never mix two different types of oil. Use the proper SAE Engine Oil according to ambient temperatures.

Engine Oil capacity (with filter)

Sign off on the engine oil replacement

- Replace Air cleaner element [Double type] Primary element. Every year or every 6 times of cleaning

- Replace Air cleaner element [Double type] Secondary element

- Replace Parking brake (cable)

- Replace Fuel line. Replace only if necessary

- Replace Radiator hose and clamp

- Replace Power steering oil line - Flush Cooling system

CAUTION! Be sure to stop the engine before changing oil filter cartridge. Allow engine to cool down sufficiently, oil can be hot and can burn.

Engine stopped and cooled down sufficiently?

Drain plugs at the bottom of the transmission case removed?

Oil completely drained into the oil pan?

Drain plugs reinstalled after draining?

Film of clean transmission oil put on the rubber seal of the new filter?

Choose the type of filter replaced

New filter quickly tightened until it contacts the mounting surface?

CAUTION! Be sure to stop the engine before changing oil filter cartridge. Allow engine to cool down sufficiently, oil can be hot and can burn.

Place an oil pan under the tractor

Remove the drain plugs (1) at the bottom of the transmission case

Screw in the drain plugs after draining

Fill new oil from filling port after removing the filling plug (2) up to the upper line of the dipstick (3)

Run the engine for a few minutes, stop it and check the oil level again, if low, add oil to prescribed level

IMPORTANT: Use only multi-grade transmission oil. Use of other oils may damage the transmission or hydraulic system. Never work the tractor immediately after changing the transmission oil. Keeping the engine at medium speed for a few minutes to prevents damage to the transmission. Do not mix different brands of oil together.

- Replace Transmission oil filter [HST]

- Check Radiator hose and clamp

- Check Power steering oil line

(Only the Check Points Different from Those for Tractors with CABIN):

- Adjust Tension of air conditioner drive belt
