Hexagon Manufacturing Intelligence Coordinate Measuring Machine GLOBAL S CHROME 15.22.10

Remove the transparent polycarbonate cup

Use a compressed air jet to remove solid residue from the filter

Was the air jet sufficient to clean the filter completely?

If necessary, wash the filter with neutral detergent and use the air jet again

Safety and Emergency Systems Check

Verify functionality of safety systems

Visual Inspection and Hardware Check

Perform visual inspection for missing or damaged parts and abnormal vibrations

Tighten any loose screws and nuts

Replace any missing screws or nuts

Inspect Jogbox cable for damage

Is the Jogbox cable in good condition?

Use a soft, clean, lint-free cloth moistened with isopropyl alcohol or heptane to clean the optical scales.

Move the moving parts of the machine to clean the entire length of the optical scale.

Let the optical scales dry before using the measuring machine.

Ensure no operations are performed on the sliding system components other than specified.

Report any counting errors found after maintenance or during use.

Check presence of anti-tilt feet

Measure distance from top ends of anti-tilt feet to bottom surface of granite

Anti-Vibration Support Inspection

Verify position of anti-vibration supports

Were any faults found in the anti-tilt feet or anti-vibration supports?

Stop the measuring system if faults are found

Check for missing or damaged parts and abnormal vibrations

Inspect guards and covers for damage or missing parts

Repair any damaged guards and covers

Replace any missing guards and covers

Pneumatic Control Unit Inspection

Check the pressure in the air supply system on the pressure gauge

Inspect devices for automatically cleaning the filters
