Terex Vehicle SS-842C

Inspect filter element for contamination

Inspect tubing going to filter body from engine for cracks or leaks

Inspect air cleaner body and gaskets for cracks or leaks

Sign off on the air cleaner inspection

Turn valve on bottom of filter (A) counter clockwise

Drain until clear fuel is present

NOTE If more than 2 oz. of fuel are drained, refilling of the jfilter is required to prevent hard starting

Was the procedure completed successfully?

Sign off on the water separator check

Oil level between the add and full marks on dip stick

Location: Filler/Drain Plug (A)

Check lubricant level in the wheel end with the filler/drain plug hole at the 3 or 9 o'clock position

Remove FillerlDrain Plug (A). Oil should run freely out of hole

Location: Fill Plug (A), Check Plug (C), Drain Plug (B)

Remove Check Plug (C) oil should flow freely from hole

Operate engine until water has reached 140 degrees F

Place drain pan directly beneath engine oil Drain Plug (B)

Clean area around engine Oil Filter (A)

Apply a thin film of clean oil around new filter gasket before installation

Fill new engine oil filter with clean oil before installation
