Terex Vehicle SS-644C

Turn valve on bottom of filter (A) counter clockwise

Drain until clear fuel is present

NOTE If more than 2 oz. of fuel are drained, refilling of the jfilter is required to prevent hard starting

Was the procedure completed successfully?

CHECK HYDRAULIC RETURN FILTER (GAUGE)

Extend boom cylinder at full speed

Lower boom as low as possible as to allow access to engine compartment

Location: Filter (A), Water Separator (B)

Wipe all dirt from area surrounding filter(s)

Thoroughly clean gasket sealing surface after filter removal

Install filter according to filter manufacturer specification

Sign off on the fuel filters replacement

- CHANGE TRANSMISSION OIL AND FILTER

- ADJUST EXTENSION -RETRACTION CHAINS

TO CHECK: Proper adjustment can be checked with a tape measure. Extend boom fully, then retract about one inch. On either side of the middle boom section estimate the center.

Place one end of the tape measure on top surface of the boom directly above estimated center.

TOLERANCE: Measurement from top surface of boom to lowest pali of extension chain should be no less than 2 3/8 inches.

TO ADJUST: If the measurement is less than 2318 inches, tighten chain anchor (A), which is located on the top, front of the large boom tube as follows:

Enter the coolant concentration

Is the coolant concentration at the factory setting of 50/50 mixture of water and ethylene-glycol based antifreeze?

Sign off on the coolant concentration check
