Stoelting Foodservice Equipment Ice Cream Machine F131-18I2-YG2

Create an account to install this asset package.

Maintenance Plans for Stoelting Foodservice Equipment Ice Cream Machine Model F131-18I2-YG2

Integrate maintenance plans directly into your work orders in MaintainX.

Ice Cream Machine Front Door Assembling

Lubrication and Installation of Spigot Bodies

Install the o-rings onto the spigot bodies and apply a thin layer of sanitary lubricant to the o-rings

Install the spigot bodies through the bottom of the front door

Fit the front door o-rings into the grooves on the rear of the front door

Front Door Assembly

Place the front door assembly on the mounting studs and push front door against the machine carefully

Ensure the pin of the front door does not touch the legs of the auger support

Securing the Front Door

Secure the front door to the machine by placing the knobs on the studs and tightening until finger tight

Run this procedure

Ice Cream Machine Cleaning

Disassembly and Cleaning

Disassemble all parts (Refer to Section 3.4 for the disassembly of machine parts)

Place all parts in 90° to 110°F (32°C to 43°C) mild detergent water and wash thoroughly

Use brushes to clean all holes in the front door, flights, mix pickup assembly, etc.

Rinsing and Sanitizing

Rinse all parts with clean 90° to 110°F (32°C to 43°C) water

Place all parts in a sanitizing solution for at least 1 minute

Let all parts air dry completely before assembling in machine

Sanitizing the Machine

Run this procedure

3 Monthly Ice Cream Machine Drive Belt Check

Safety Warning

WARNING: Hazardous voltage. The machine must be disconnected from electrical supply before servicing. Failure to disconnect power before servicing could result in death or serious injury.

WARNING: Service must be completed by a qualified electrician/refrigeration specialist. Improper service may cause severe personal injury, or damage to the machine.

Drive Belt Inspection

Check drive belts for wear

Tighten drive belts if necessary

Run this procedure

1 Daily Ice Cream Machine Check

Safety Warning

Hazardous voltage. The machine must be disconnected from electrical supply before servicing. Failure to disconnect power before servicing could result in death or serious injury.

Check for worn or broken parts

Replace parts as necessary

Check for any unusual noise or condition

Repair immediately if any unusual noise or condition is found

Service must be completed by a qualified electrician/refrigeration specialist. Improper service may cause severe personal injury, or damage to the machine.

Run this procedure

Ice Cream Machine Auger Disassembling

Initial Disassembly

Remove the front auger support and bushing

Remove the auger assembly from the machine

Pull the auger out of the freezing cylinder slowly

Plastic Flights and Springs Removal

Carefully remove each of the plastic flights with springs as the auger is being pulled out

Rear Seal Assembly Handling

Keep the rear of the auger tipped up once it is clear of the freezing cylinder to prevent the rear seal assembly from dropping

Wipe the lubricant off of the hex end of the auger with a paper towel

Run this procedure
