Lingong Heavy Machinery Work Platform AS2632E

Is the pressure of the hydraulic system normal?

Is the lift system hydraulic pressure normal?

Is the steering system hydraulic pressure normal?

Is the driving system hydraulic pressure normal?

Check for loose or damaged components

Pre-Operation Inspection Responsibilities

Operator is responsible for pre-operation inspection and routine maintenance.

Perform visual inspection daily before each work shift.

Use inspection to confirm if routine maintenance is required.

Pre-Operation Inspection Process

Ensure the manual is complete, legible, and stored in the manual box on the platform.

Ensure all labels are clear, readable, and appropriately placed.

Check for hydraulic oil leakage and proper oil level.

Check for battery fluid leakage and suitable liquid level. Add distilled water if required.

Press the enable switch on the control handle

Push the control handle forward

Return the handle to the center position

Did the machine move forward and then stop?

Push the control handle backward

Return the handle to the center position

Did the machine move backward and then stop?

Press the drive function selector switch

Check if the drive function indicator lights up

Press the enable switch on the control handle

Press the rocker switch on top of control handle to turn left

Press the rocker switch on top of control handle to turn right

Confirm the machine turns left when the leftward direction is selected

Confirm the machine turns right when the rightward direction is selected

Ensure the enable switch on the control handle is not pressed

Move the control handle forward or backward. Are all lift functions non-operational?

Lift Function Selector and Enable Switch Test

Press the lift function selector button

Press the enable switch on the control handle

Move the control handle backward. Does the platform elevate and the pothole guards deploy?

Platform Control Handle Release Test

Release the platform control handle. Does the platform stop elevating?
