Lingong Heavy Machinery Work Platform AS1932E

Create an account to install this asset package.

Maintenance Plans for Lingong Heavy Machinery Work Platform Model AS1932E

Integrate maintenance plans directly into your work orders in MaintainX.

Lift Function And Function Enable Switch Testing

Initial Control Handle Test

Ensure the enable switch on the control handle is not pressed

Move the control handle forward or backward. Are all lift functions non-operational?

Lift Function Selector and Enable Switch Test

Press the lift function selector button

Press the enable switch on the control handle

Move the control handle backward. Does the platform elevate and the pothole guards deploy?

Platform Control Handle Release Test

Release the platform control handle. Does the platform stop elevating?

Run this procedure

Operation Of Tilt Sensor Testing

Pre-Test Setup

Ensure the platform is completely lowered

Drive two wheels on the same side of the machine up on a 1.37×7.9in (3.5×20cm) block

Tilt Sensor Test

Enter the height to lift the platform as per the table

Did the platform stop moving and the tilt alarm sound at 120 times per minute?

Is the drive function disabled in both forward and reverse directions?

Post-Test Procedure

Lower the platform

Run this procedure

Workstation Inspection

Warning

Operation is forbidden unless the following safe operating principles of the machine are understood and performed.

Notice

The workstation inspection must be performed and proper operating procedures understood before the next step.

Function test has been performed

Machine is used as described in this manual

General Information

Using the Workstation Inspection procedures, the operator can determine if the safe operation of machine is possible from the workstation. The operator shall carry out this process before operating the machine from the workstation.

Understanding the hazards of the workstation are the responsibilities of the operator. Avoid these hazards while moving, delivering, or operating the machine.

Run this procedure

1 Daily Hydraulic System Check

Hydraulic Pressure Checks

Is the pressure of the hydraulic system normal?

Is the lift system hydraulic pressure normal?

Is the steering system hydraulic pressure normal?

Is the driving system hydraulic pressure normal?

Hydraulic System Integrity

Check for loose or damaged components

Check for damage or leaks

Hydraulic Oil Level

Run this procedure
