Leybold Vacuum Pump TURBOVAC 250i DN100ISO-K
Create an account to install this asset package.
Maintenance Plans for Leybold Vacuum Pump Model TURBOVAC 250i DN100ISO-K
Integrate maintenance plans directly into your work orders in MaintainX.
Pump Cleaning
5.1 Cleaning
Clean the turbomolecular pump of dust with a dry cloth, if required.
Check if the converter has collected grime (dust, moisture) on the inside.
Ensure no grime is present to avoid malfunctions, overheating, or short circuits.
Note if Leybold Service Department assistance is required for cleaning the converter.
Bearing Maintenance
Maintenance
Determine if bearing replacement is required
Contact after sales service for on-site bearing replacement
Request a quotation for bearing replacement at Leybold Service Center
1 Yearly Air Filter Maintenance
4.1 Media compatibility / purge gas
Verify media compatibility
Check purge gas
Inspect air filters
Change air filters
Pump Startup Check
Switching on
Switch on the power supply.
Verify all LEDs come on sequentially and drive electronics are running up.
Enter the maximum starting pressure for the turbomolecular pump.
Switch on the turbomolecular pump via pins 7 and 8 of the socket REMOTE (X1).
Confirm the turbomolecular pump accelerates and the green LED flashes.
Is the green LED lit permanently indicating normal operation?
Cautionary Measures
Avoid influences of shock and vibration when the pump is running.
80000 Hourly Rotor Unit Maintenance
5 Maintenance
Observe Safety information 0.1.7
Exchange the rotor unit after 80,000 operating hours
Contact Leybold Service for rotor unit maintenance
Find the nearest Leybold service center address on www.leybold.com
Consider advancing maintenance work for high pump loads
Consult Leybold for maintenance recommendations
Parts for Leybold Vacuum Pump TURBOVAC 250i DN100ISO-K
Access the parts list for your equipment in MaintainX.
Power Supply Turbo.Power Integra Incl. 0.3 M Cable
800100V0003
Cable Turbovac I/Ix - Turbo.Power Integra 1 M
800096V0100
Cable Turbovac I/Ix - Turbo.Power Integra 3 M
800096V0300
Cable Turbovac I/Ix - Turbo.Power Integra 5 M
800096V0500
Power Supply And Control Unit Turbo.Control 300
800100V0001
Power Supply Turbo.Power Integra Incl. 0.3 M Cable
800100V0003
Cable Turbovac I/Ix - Turbo.Power Integra 1 M
800096V0100
Cable Turbovac I/Ix - Turbo.Power Integra 3 M
800096V0300
Cable Turbovac I/Ix - Turbo.Power Integra 5 M
800096V0500
Power Supply And Control Unit Turbo.Control 300
800100V0001
Power Supply Turbo.Power Integra Incl. 0.3 M Cable
800100V0003
Cable Turbovac I/Ix - Turbo.Power Integra 1 M
800096V0100
Cable Turbovac I/Ix - Turbo.Power Integra 3 M
800096V0300
Cable Turbovac I/Ix - Turbo.Power Integra 5 M
800096V0500
Power Supply And Control Unit Turbo.Control 300
800100V0001
