Wulftec Heavy‑Duty High‑Profile Pallet Wrapper WHP-200

No chain on Cumulus 300 because there's a ring gear.

Four (4) bolts on the side of the drive box slackened

Tension adjuster bolt backed off

Chain link undone and replaced with a new one of the appropriate length

Chain tension adjusted by turning the adjuster clockwise

Four (4) bolts on the drive box that secures the transmission tightened

Sign off on the chain replacement

Warning: This procedure requires trained personnel with PPE!

Oil baths filled with EP 80 gear oil?

Enter the number of pallets processed since last check

To fill oil baths, position the outer filler plug in line with the punch mark located on the main frame and remove the two 1/4\ pipe plugs with a 1/4\" Allen key."

Sign off on the cam followers check

Ensure that dancer bar is fully retracted to home position

Install or adjust cam with an angle of 60° approx

Adjust the sensor so it barely touches Cam

At maximum dancer bar travel, make sure that sensor to cam gap is approx. 8mm (5/16\)"

If necessary repeat step 3, slightly modifying the angle to meet step 7 requirements

Make sure that minimum sensor to cam gap is not more than .005\ -. 010\""

Warning: This procedure requires trained personnel with PPE!

Oil baths filled with EP 80 gear oil?

Number of pallets processed since last check

To fill oil baths, position the outer filler plug in line with the punch mark located on the main frame.

Upload a photo of the filler plug positioning

Remove the two (2) 1/4\ pipe plugs with a 1/4\" Allen key."

Sign off on the cam followers check

Warning: This procedure requires trained personnel with PPE!

Oil baths filled with EP 80 gear oil?

Number of pallets processed since last check

To fill oil baths, position the outer filler plug in line with the punch mark located on the main frame.

Upload a photo of the punch mark on the main frame

Remove the two (2) 1/4\ pipe plugs with a 1/4\" Allen key."

Enter the oil level in the bath

Sign off on the cam followers check
