Trane Split System Cooling Condenser TTA120D

Disconnect all electric power, including remote disconnects and discharge all motor start/run capacitors before servicing.

Follow proper lockout/tagout procedures to ensure the power cannot be inadvertently energized.

Verify with an appropriate voltmeter that all capacitors have discharged.

Ensure compressor is not operated or powered under vacuum conditions.

Perform all of the monthly maintenance inspections.

Check unit superheat and record the reading in the “Maintenance Log.”

Ensure all electrical connections are complete and system is ready to operate.

Install compressor access panel and route manifold hoses through refrigerant gauge access holes.

Turn on power to the unit and allow the system to run for 5 to 10 minutes to stabilize operating conditions.

Measure airflow across the indoor coil and compare with fan performance data.

Compare discharge pressure and liquid temperature to the Charging Charts.

Add or remove refrigerant (liquid only) as required to obtain correct discharge pressure and liquid temperature.

Check suction line superheat and condenser sub-cooling to ensure proper operation.

Ensure only dry nitrogen with a pressure regulator is used for pressurizing unit.

Confirm no use of acetylene, oxygen, or compressed air for pressure testing.

Verify no use of open flame for gas leak detection.

Complete brazing operation of refrigerant lines to both outdoor and indoor units.

Pressurize the system through the service valve with dry nitrogen to 200 psi.

Check all field joints for leaks using soap bubbles or other methods.

If leaks are found, release pressure, repair, and repeat leak test.

Disconnect all electric power, including remote disconnects and discharge all motor start/run capacitors before servicing.

Follow proper lockout/tagout procedures to ensure the power cannot be inadvertently energized.

Verify with an appropriate voltmeter that all capacitors have discharged.

Ensure the compressor is not operated or powered while under a vacuum.

Monthly Maintenance Inspections

Check unit wiring to ensure all connections are tight and that the wiring insulation is intact.

Inspect the condenser coils for dirt and debris.

Inspect individual pieces of the shipment before accepting the unit

Inspect the unit for concealed damage before storage and as soon as possible after delivery

Was concealed damage discovered?

Take photos of the damage if possible

Notify the carrier’s terminal of damage immediately by phone and by mail

Request an immediate joint inspection of the damage by the carrier and the consignee

Notify the sales representative and arrange for repair

Has the damage been inspected by the carrier’s representative?
