Raymond Walkie Pallet Truck Electric Pallet Jack 8400

Warning: This inspection requires trained personnel with PPE!

Commutator has surface condition and high mica

If the armature on your motor does not have mica undercut, do not attempt to cut it.

If commutators are not correctly maintained, carbon dust can collect in the grooves between the segments. This can lead to a short circuit in the armature.

Good commutation is indicated by a dark brown polished commutator and an evenly polished brush wearing surface.

Upload a photo of the commutator surface

If the commutator appears rough, pitted, or has signs of burning or heavy arcing between the commutator bars, remove the motor for service.

Sign off on the DC Electric Motors Inspection

Warning: This maintenance check requires trained personnel with PPE!

Is the truck operational in the selected environment?

Enter the truck's hour meter reading

Describe any issues found during the check

Sign off on the truck maintenance

Warning: This maintenance check requires trained personnel with PPE!

If truck is not operational, report the issues to the maintenance team and stop the procedure

Choose the type of service done

Truck passed the post-maintenance test?

Sign off on the truck maintenance

Warning: This maintenance check requires trained personnel with PPE!

Push the spring clip toward the pump housing

Grasp the suction tube with the filter screen and pull out of pump housing

Clean the filter screen and magnet at the bottom of the suction tube with a suitable solvent

Blow dry with clean, dry compressed air

Inspect the filter screen and tube for damage and replace if necessary

Enter the amount of gear oil in the drive housing

Change hydraulic fluid in the hydraulic reservoir

Push the spring clip toward the pump housing
