FG Wilson Generator Set P33-3

Measure the electrolyte level above the plates/grids

Is the electrolyte level covering the plates/grids?

Is the electrolyte level below the plates/grids?

Add distilled water if necessary

Is the fluid level just touching the bottom of the filler tubes?

Ensure the generator set is stopped and there are no active or present shutdown conditions

Priming Procedure with Base Tank

Operate the priming switch for the standard pre-set 2 minute priming cycle

Did the engine start within 3 crank cycles?

Repeat the prime procedure if the engine did not start within 3 crank cycles

Priming Procedure with Remote Tank

Ensure that the engine is stopped before any servicing or repair is performed

Ensure that the area around the cap on the Diesel Exhaust Fluid (DEF) tank is clean

Using a suitable tool, press the tabs to release the tabs

Remove the filter screen from DEF tank neck adapter

Filter Screen Cleaning or Replacement

Can the filter screen be cleaned?

Applicable to Perkins 1506, 2206, 2506, 2806 engines fitted with pre-filter / water separator

Ensure the drain valve is tightened securely to prevent air from entering the fuel system

Catch the draining water in a suitable container

Perform a visual walk-around inspection before starting the generator set

Check for loose fastenings, worn belts, or loose connections

Ensure fan and exhaust guards are correctly positioned and securely fixed

Wipe clean all filler caps before servicing the engine or topping up fluids

Is there any type of leak (coolant, lubricating oil, or fuel)?

Describe the source and corrective action for any observed leaks

Remove accumulated grease and/or oil on the engine by steam cleaning or high-pressure water jet
