FG Wilson Generator Set P275-5

Ensure generator is in good condition

Record initial generator load percentage

Is the generator load at least 50%?

Record start time of load check

Inspect battery condition using a torch if necessary

Check for any marks, dents, or leaks on the battery

Contact local Dealer if severe dents or leaks are found

Ensure all load is removed before disconnecting the battery

Disconnect the negative cable first

Perform a visual walk-around inspection before starting the generator set

Check for loose fastenings, worn belts, or loose connections

Ensure fan and exhaust guards are correctly positioned and securely fixed

Wipe clean all filler caps before servicing the engine or topping up fluids

Is there any type of leak (coolant, lubricating oil, or fuel)?

Describe the source and corrective action for any observed leaks

Remove accumulated grease and/or oil on the engine by steam cleaning or high-pressure water jet

Ensure that the engine is stopped before any servicing or repair is performed

Ensure that the area around the cap on the Diesel Exhaust Fluid (DEF) tank is clean

Press the tabs to release the filter screen from DEF tank neck adapter

Remove the filter screen from DEF tank neck adapter

Measure DEF quality using a refractometer

Does the DEF meet ISO 22241-1 requirements?

Is it necessary to drain the tank?

Drain the tank if necessary and refill with DEF that meets ISO 22241-1
