Pompetravaini Centrifugal Pump TBK

!DANGER: Danger due to fluids in pressure. Carry out sealing tests provided with apposite protective devices.

Ensure all protective devices are in place

Verify installation completion for

Record the static pressure reading

Is the static pressure within the acceptable range?

Record the vacuum pressure reading

Is the vacuum pressure within the acceptable range?

!CAUTION: Possible contact with hazardous media and hazardous substances, cold or warm. Operate only provided with apposite protective devices.

Ensure all protective devices are worn

Verify that the cleaning area is clear of unnecessary personnel

Remove loose materials from piping

Remove foreign particles from reservoirs

Has welding been performed on the piping or components?

If welding was performed, ensure thorough cleaning of welded areas

Danger due to collision, crushing or harm. Wait for the complete pump stopping before handling the unit.

Ensure the pump is completely stopped before handling.

Drain the pump or close the pipes using a valve to prevent sudden rotation.

Wait for the pump to cool down to avoid contact with high temperature surfaces.

Ensure maintenance is carried out when the pump is at a standstill, disconnecting the power supply and any other connection.

Ensure power supply is restored only by the operator performing the maintenance.

Ensure the presence of at least two operators and inform the foreman about the maintenance in progress.

Wear proper safety equipment (hard hat, safety glasses, gloves, safety shoes, etc.).

Disconnect the electrical power supply and, if required, disconnect the electrical cables from the motor.

Ensure the engine is off and cooled down

Gather necessary tools and materials for oil change

Remove vent plug of the bearing frame

Pour oil into the bearing frame through the hole of plug till you can see oil in the oil-filler elbow

Fill the oil-filler pouring oil directly into the oil-cruet and NOT into the elbow

Replace the cruet in normal position

Adjustment of Packing Seals Without External Flushing

Loosen the stuffing box nuts to allow a strong drip to escape

Verify the extent of the leak (drops per minute)

Tighten the stuffing box nuts progressively until the leak is reduced to a controlled drip

Wait a few minutes and verify the stabilized leak rate (drops per minute)

Is the leak rate within the acceptable range (60-200 drops per minute)?

Measure the temperature of the liquid that comes out

Is the temperature at least 10°C lower than the boiling temperature and below 90°C?

Is the dripping insufficient (high temperature)?
