JCB Telescopic Handler 509-42

Create an account to install this asset package.

Maintenance Plans for JCB Telescopic Handler Model 509-42

Integrate maintenance plans directly into your work orders in MaintainX.

Oil Level Check

Warning: Failure to replace the oil and filter at the recommended interval could cause serious engine failure.

Machine made safe according to PIL 01-03

Access to the engine obtained

Oil level is between the two marks on the dipstick

Is it necessary to add oil?

If necessary, add recommended oil through one of the filler points.

Sign off on the oil level check

Run this procedure

Tensioner Replacement

Before Removal

Machine made safe

Engine safe to work on

Access to engine obtained

Drive belt removed

Remove

Tensioner assembly removed

Install

Tensioner assembly installed

Run this procedure

Air Filter Replacement

Do not attempt to wash or clean the elements, they must only be renewed.

A new inner element must be installed at least every other time the outer element is changed. As a reminder, mark the inner element with marker pen each time the outer element is changed.

Remove:

1. Make the machine safe. Refer to (PIL 01-03).

2. Get access to the engine.

3. Depress the clips and lift off the cover.

4. Remove the outer element. Take care not to tap or knock the element.

5. If the inner element is to be changed, lift up pulls and remove the inner element.

Install:

Run this procedure

Crankcase Ventilation Filter Replacement

Make the machine safe. Refer to (PIL 01-03).

Get access to the engine. Refer to (PIL 06-06).

Rotate the filter cover anti-clockwise and remove.

Lift out the filter element and discard it.

Clean the inside of the filter housing. Remove all oil and sludge contamination.

Make sure that the oil drain in the bottom of the filter housing is not blocked with sludge.

Install a new filter element. Make sure that the correct type of filter element is installed.

Align the arrows on both parts to install the filter cover.

Sign off on the filter replacement

Run this procedure

Air Filter Check

The air filter element (s) should be changed at the recommended service interval, refer to the Maintenance Schedules. Refer to: PIL 78-24.

Check all the hose connections for loose installations and damaged hose clamps

Look specifically for splits or cracks in the hoses

Pay particular attention to the connections on the air intake to turbo compressor and on the crossover tube.

Renew any damaged components.

In addition, most air filter housings will be installed with a vacuum switch. The switch will detect if there is a restriction on the air intake, and activate warning indicators such as an audible alarm and/or a visual indicator.

Is there a restriction on the air intake?

Sign off on the air filter check

Run this procedure
