JCB Backhoe Loader 3CX-17
Need answers fast?
Explore the manual using AI.
The JCB Backhoe Loader 3CX-17 is a versatile and powerful piece of industrial equipment designed for construction and excavation tasks. Known for its durability and efficiency, this backhoe loader combines advanced technology with robust performance, making it an essential asset for any job site.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for JCB Backhoe Loader 3CX-17
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
JCB Backhoe Loader 3CX-17
Create an account to install this asset package.
Maintenance Plans for JCB Backhoe Loader Model 3CX-17
Integrate maintenance plans directly into your work orders in MaintainX.
Loader Check
Inspect steelwork for damage
Note damaged paintwork for future repair
All pivot pins are correctly in place and secured by their locking devices
Steps and handrails are undamaged and secure
No broken or cracked window glass
Replace damaged items
All bucket teeth are undamaged and secure
All lamp lenses are undamaged
Tyres are undamaged and free from penetration by sharp objects
500 Hours / 6 Monthy Loader Transmission Maintenance
Check Transmission Oil Level
Change Transmission Filter
Check Axle Oil Level (incl. Hubs when applicable)
Change Axle Oil - Limited Slip Differential
Check Tyre Pressures/Condition
Check Front Hub Bearings
Security/Grease Drive Shafts
Check Steer Axle Movement/Shimming
Grease Steer Axle Pivots and Linkages
1000 Hours / 1 Yeary Loader Hydraulics Maintenance
Check Hydraulic Oil Level
Change Oil Filter
Check Rams - Chrome Condition
Sign off on the loader hydraulics maintenance
2000 Hours / 2 Yeary Loader Engine Maintenance
- Change Engine Oil and Filter (AK and AR Build)
- Change Engine Oil and Filter (RE and RG Build)
- Change Engine Air Cleaner Outer Element
- Change Air Cleaner Inner Element
- Change Engine Fuel Filter (AK and AR Build)
- Change Engine Fuel Filter (RE and RG Build)
- Clean Lift Pump Strainer (AK and AR Build Only)
- Check Coolant Quality/Level
- Drain and Clean Engine Fuel Sedimenter
500 Hours / 6 Monthy Loader Hydraulics Maintenance
Check Hydraulic Oil Level
Change Oil Filter
Check Rams - Chrome Condition
Sign off on the loader hydraulics maintenance
Parts for JCB Backhoe Loader 3CX-17
Access the parts list for your equipment in MaintainX.
Male Adapter, 3/8 in. x 3/8 in.
1604/0003
Male Adapter, 1 in M x 1 in M BSP
1604/0008
Male Adapter, 1/2 in. x 1/2 in.
1604/0004
Bonded Washer, 1/2 in. BSP
1406/0018
JCB Multi-Gasket, 50ml, A Medium Strength Sealant Suitable For All Sizes Of Gasket Flanges, And For Hydraulic Fittings Of 25-65Mm Diameter
4102/1212
Male Adapter, 3/8 in. x 3/8 in.
1604/0003
Male Adapter, 1 in M x 1 in M BSP
1604/0008
Male Adapter, 1/2 in. x 1/2 in.
1604/0004
Bonded Washer, 1/2 in. BSP
1406/0018
JCB Multi-Gasket, 50ml, A Medium Strength Sealant Suitable For All Sizes Of Gasket Flanges, And For Hydraulic Fittings Of 25-65Mm Diameter
4102/1212
Male Adapter, 3/8 in. x 3/8 in.
1604/0003
Male Adapter, 1 in M x 1 in M BSP
1604/0008
Male Adapter, 1/2 in. x 1/2 in.
1604/0004
Bonded Washer, 1/2 in. BSP
1406/0018
JCB Multi-Gasket, 50ml, A Medium Strength Sealant Suitable For All Sizes Of Gasket Flanges, And For Hydraulic Fittings Of 25-65Mm Diameter
4102/1212
Unlock efficiency
with MaintainX CoPilot
MaintainX CoPilot is your expert colleague, on call 24/7, helping your team find the answers they need to keep equipment running.
