JCB Backhoe Loader 3CX
Create an account to install this asset package.
Maintenance Plans for JCB Backhoe Loader Model 3CX
Integrate maintenance plans directly into your work orders in MaintainX.
Loader Cleaning
- Clean the machine
Park the machine on firm level ground, engage the parking brake and set the transmission to neutral. Lower the attachments to the ground and stop the engine
Clean the machine using water and/or steam. Do not allow mud, debris etc to build upon the machine, pay particular attention to the following areas:
1. Backhoe hoses passing through mainframe
2. Around twin slew rams
3. Twin ram slew recess in chassis (centremount)
4. Kingpost slide rails (sideshift)
5. Kingpost hose tray and bottom 'shelf' (sideshift)
6. Recess between slew ram and kingpost casting (sideshift)
100 Hours Loader Engine Maintenance
Change Engine Oil and Filter (AK and AR Build)
Change Engine Fuel Filter (AK and AR Build)
Clean Lift Pump Strainer (AK and AR Build Only)
Check Coolant Quality/Level
Drain and Clean Engine Fuel Sedimenter
Check Fan Belt Tension/Condition
Check Engine Mounting Bolts for Tightness
Check All Hoses - Condition
Sign off on the 100 Hours Loader Engine Maintenance
2000 Hours / 2 Yeary Loader Hydraulics Maintenance
Sample/Change Hydraulic Oil
Change Oil Filter
Check Rams - Chrome Condition
Sign off on the loader hydraulics maintenance
10 Hours / 1 Daily Loader Maintenance
Check Engine Oil Level
Check Coolant Quality/Level
Check Transmission Oil Level
Check Tyre Pressures
Check Tyre Condition
Grease Front Axle Main Pivot
Check Hydraulic Oil Level
2000 Hours / 2 Yeary Loader Transmission Maintenance
Change Transmission Oil
Change Transmission Filter
Change Axle Oil (incl. Hubs when applicable)
Change Axle Oil - Limited Slip Differential
Check Tyre Pressures/Condition
Check Front Hub Bearings
Clean Transmission Strainer
Security/Grease Drive Shafts
Check Steer Axle Movement/Shimming
Parts for JCB Backhoe Loader 3CX
Access the parts list for your equipment in MaintainX.
Flow Test Adapter
460/15708
Bonded Washer, 3/4 in. BSP
1406/0021
Bonded Washer, 1.1/4 in. BSP
1406/0029
Banjo Bolt
460/15707
Clear Silicone Sealant, To Seal Butt Jointed Glass
4102/0933
Flow Test Adapter
460/15708
Bonded Washer, 3/4 in. BSP
1406/0021
Bonded Washer, 1.1/4 in. BSP
1406/0029
Banjo Bolt
460/15707
Clear Silicone Sealant, To Seal Butt Jointed Glass
4102/0933
Flow Test Adapter
460/15708
Bonded Washer, 3/4 in. BSP
1406/0021
Bonded Washer, 1.1/4 in. BSP
1406/0029
Banjo Bolt
460/15707
Clear Silicone Sealant, To Seal Butt Jointed Glass
4102/0933
