Hyundai Forklift 45DS-7E

Examine truck for obvious damage

Check overhead guard for crack or obvious damage

Check backrest for crack or obvious damage

Check forks for crack or obvious damage

If yes, describe the damage or leak

Upload a photo of the replaced Air cleaner element

Upload a photo of the replaced Fuel filter

Warning: Replace the fuel filler when the engine is cool. Carry out this maintenance in a place away from fire. Removing the fuel filler will produce explosive fumes. Wipe off any spilled fuel or oil immediately from the truck or surrounding area.

Upload a photo of the new cartridge with fuels coat the surface of the packing lightly with engine oil, then install.

Warning: When the fuel filter is replaced, the fuel system should be bled to remove air if the fuel supply is exhausted during driving.

Warning: BATTERIES EMIT EXPLOSIVE GAS. Do not smoke or have open flames or sparks in battery charging areas or near batteries. An explosion can result and cause injury or death.

Warning: Hydrogen gas is produced during normal battery operation. Hydrogen can explode if flames, sparks, or lighted tobacco are brought near the battery. When charging or using a battery in an enclosed space, always provide ventilation and shield your eyes. Wear safety glasses when working around batteries.

Change oil after removing drain plug.

Add oil until it just begins to flow out of the oil level.

Dispose of used oil in locally approved manner.

Engine oil and oil filter (Initial 50 hours only) Change/Replace

Warm up engine oil then park the truck in level place with forks lowered. Stop the engine and apply parking brake.

Remove drain plug and drain engine oil.

Also replace the engine oil filter. Check oil level using dipstick after changing the engine oil. Dispose of old oil in locally approved manner.

Warning: Do not put hands into the mast.

Forks raised 100 to 150mm(4 to 6in) from ground

Both chains have approximately same amount of slack

Locknut loosened and nut turned

Tension on the lift chain equalized

Sign off on the lift chain tension check

The seat adjustable to fit the contours of the operator's body. It will reduce operator fatigue due to long works hours and enhance work efficiency.

(1) Forward/Backward adjustment(A)

1 Pull lever A to adjust seat forward or back ward.

2 The seat can be moved forward and backward over 156mm in 12 steps.

1 Pull lever B to adjustment seat back rest.

2 The backrest of the seat can be reclined to 31+-2Áforward and 34.6+-2Ábackward.

1 Adjusting handle to the operator's weight.
