Hyundai Forklift 60DS-7E

OSHA-approved eye protection rated for 200kPa(30psi) is required for air cleaning operation. When changing oil, remove strainer and clean it with flushing oil. Blow dry compressed air from inside of strainer to outside and install when completely dry.

Dispose of oil in locally approved manner.

Bleed the air after checking the oil level as below;

Check for mast overhead clearance.

Fully raise and lower mast and also fully tilt it forward and backward several times.

Change oil after removing drain plug.

Add oil until it just begins to flow out of the oil level.

Dispose of used oil in locally approved manner.

Engine oil and oil filter (Initial 50 hours only) Change/Replace

Warm up engine oil then park the truck in level place with forks lowered. Stop the engine and apply parking brake.

Remove drain plug and drain engine oil.

Also replace the engine oil filter. Check oil level using dipstick after changing the engine oil. Dispose of old oil in locally approved manner.

Examine truck for obvious damage

Check overhead guard for crack or obvious damage

Check backrest for crack or obvious damage

Check forks for crack or obvious damage

If yes, describe the damage or leak

Hydraulic oil return filter Replace

Park the truck in a level place and lower the forks.

Then stop the engine and apply the parking brake.

Change oil after removing drain plug on tank bottom

Transmission oil & filter Change

(1) These are the parts which the operator cannot judge the remained lifetime of them by visual inspection.

(2) Repair or replace if an abnormality of these parts is found even before the recommend replacement interval.

Replacement of consumable service parts is not covered under warranty.

Packing, seal, and O-ring steering cylinder
