Hyundai Forklift 50D-7E

Hydraulic oil return filter Replace

Park the truck in a level place and lower the forks.

Then stop the engine and apply the parking brake.

Change oil after removing drain plug on tank bottom

Transmission oil & filter Change

Replace the fuel filler when the engine is cool. Carry out this maintenance in a place away from fire. Removing the fuel filler will produce explosive fumes. Wipe off any spilled fuel or oil immediately from the truck or surrounding area.

1 Using a filter wrench, remove the cartridge.

2 Fit the new cartridge with fuels coat the surface of the packing lightly with engine oil, then install.

When the fuel filter is replaced, the fuel system should be bled to remove air if the fuel supply is exhausted during driving.

(1) These are the parts which the operator cannot judge the remained lifetime of them by visual inspection.

(2) Repair or replace if an abnormality of these parts is found even before the recommend replacement interval.

Replacement of consumable service parts is not covered under warranty.

Packing, seal, and O-ring steering cylinder

Engine stopped before servicing?

Door opened, wing bolt loosened and recircular plenum assembly removed?

Recircular plenum cleaned using pressurized air (Below 2kgf/cm2, 28psi)?

Filter inspected after cleaning?

Is the filter damaged or badly contaminated?

PRECAUTIONS FOR USING AIR CONDITIONER

Window opened once every one hour when using the air conditioner for a long time?

Engine oil and oil filter check

Lift chain check and lubrication

Mast roller check and lubrication

Lift cylinder rod end check and lubrication

Lift cylinder tube end check and lubrication

Tilt cylinder rod end check and lubrication

Tilt cylinder tube end check and lubrication
