Hyundai Forklift 40DS-7E

Truck for obvious damage and leaks

Warning plates and decals condition

Lift chain and fastener condition

Hydraulic oil return filter Replace

Park the truck in a level place and lower the forks.

Then stop the engine and apply the parking brake.

Change oil after removing drain plug on tank bottom

Transmission oil & filter Change

OSHA-approved eye protection rated for 200kPa(30psi) is required for air cleaning operation.

Dispose of oil in locally approved manner.

Oil changed and strainer cleaned with flushing oil

Strainer dried with compressed air from inside to outside and installed when completely dry

Air bled after checking the oil level

Checked for mast overhead clearance

Mast fully raised and lowered and also fully tilted forward and backward several times

Examine truck for obvious damage

Check overhead guard for crack or obvious damage

Check backrest for crack or obvious damage

Check forks for crack or obvious damage

If yes, describe the damage or leak

Change oil after removing drain plug.

Add oil until it just begins to flow out of the oil level.

Dispose of used oil in locally approved manner.

2 When changing oil, remove strainer and clean it with flushing oil.

OSHA approved eye protection rated for 200kPa(30psi) is required for air cleaning operation.

Blow dry compressed air from the inside of strainer to outside and install when completely dry.
