Hyundai Forklift 80D-7E

(1) These are the parts which the operator cannot judge the remained lifetime of them by visual inspection.

(2) Repair or replace if an abnormality of these parts is found even before the recommend replacement interval.

Replacement of consumable service parts is not covered under warranty.

Every 1 years: Master cylinder and wheel cylinder caps dust seals

Change oil after removing drain plug.

Add oil until it just begins to flow out of the oil level.

Dispose of used oil in locally approved manner.

Engine oil and oil filter (Initial 50 hours only) Change/Replace

Warm up engine oil then park the truck in level place with forks lowered. Stop the engine and apply parking brake.

Remove drain plug and drain engine oil.

Also replace the engine oil filter. Check oil level using dipstick after changing the engine oil. Dispose of old oil in locally approved manner.

Examine truck for obvious damage

Check overhead guard for crack or obvious damage

Check backrest for crack or obvious damage

Check forks for crack or obvious damage

If yes, describe the damage or leak

Replace the fuel filler when the engine is cool. Carry out this maintenance in a place away from fire. Removing the fuel filler will produce explosive fumes. Wipe off any spilled fuel or oil immediately from the truck or surrounding area.

1 Using a filter wrench, remove the cartridge.

2 Fit the new cartridge with fuels coat the surface of the packing lightly with engine oil, then install.

When the fuel filter is replaced, the fuel system should be bled to remove air if the fuel supply is exhausted during driving.

Engine stopped before servicing?

Door opened, wing bolt loosened and recircular plenum assembly removed?

Recircular plenum cleaned using pressurized air (Below 2kgf/cm2, 28psi)?

Filter inspected after cleaning?

Is the filter damaged or badly contaminated?

PRECAUTIONS FOR USING AIR CONDITIONER

Window opened once every one hour when using the air conditioner for a long time?
