Hyundai Forklift 60DF-7

Engine oil and oil filter check

Lift chain check and lubrication

Mast roller check and lubrication

Lift cylinder rod end check and lubrication

Lift cylinder tube end check and lubrication

Tilt cylinder rod end check and lubrication

Tilt cylinder tube end check and lubrication

Change oil after removing drain plug.

Add oil until it just begins to flow out of the oil level.

Dispose of used oil in locally approved manner.

2 When changing oil, remove strainer and clean it with flushing oil.

OSHA approved eye protection rated for 200kPa(30psi) is required for air cleaning operation.

Blow dry compressed air from the inside of strainer to outside and install when completely dry.

Warning: Do not put hands into the mast.

Forks raised 100 to 150mm(4 to 6in) from ground

Both chains have approximately same amount of slack

Locknut loosened and nut turned

Tension on the lift chain equalized

Sign off on the lift chain tension check

Engine stopped before servicing?

Open the door, loosen the wing bolt and remove the recircular plenum assembly.

Recircular plenum assembly removed?

Clean the recircular plenum using a pressurized air(Below 2kgf/cm2, 28psi).

Inspect the filter after cleaning. If it is damaged or badly contaminated, use a new filter.

Filter inspected and replaced if necessary?

PRECAUTIONS FOR USING AIR CONDITIONER

OSHA-approved eye protection rated for 200kPa(30psi) is required for air cleaning operation. When changing oil, remove strainer and clean it with flushing oil. Blow dry compressed air from inside of strainer to outside and install when completely dry.

Dispose of oil in locally approved manner.

Bleed the air after checking the oil level as below;

Check for mast overhead clearance.

Fully raise and lower mast and also fully tilt it forward and backward several times.
