Fanuc Robot Arc Mate 100iD
Create an account to install this asset package.
Maintenance Plans for Fanuc Robot Model Arc Mate 100iD
Integrate maintenance plans directly into your work orders in MaintainX.
6720 Hourly Maintenance
Check for external damage or peeling paint
Check for water
Cleaning the controller ventilation system
7680 Hourly / 2 Yearly Maintenance
Check for external damage or peeling paint
Check for water
Check the mechanical cable and welding power cable (Damaged or twisted)
Check the end effector (hand) cable
Check the motor connector. (Loosening)
Tighten the end effector bolt
Tighten the cover and main bolt
Check the fixed mechanical stopper and adjustable mechanical stopper
Remove spatter and dust etc.
11520 Hourly / 3 Yearly Maintenance
Check for external damage or peeling paint
Check for water
Check the mechanical cable and welding power cable (Damaged or twisted)
Check the end effector (hand) cable
Check the motor connector. (Loosening)
Tighten the end effector bolt
Tighten the cover and main bolt
Check the fixed mechanical stopper and adjustable mechanical stopper
Remove spatter and dust etc.
14400 Hourly Maintenance
Check for external damage or peeling paint
Check for water
Cleaning the controller ventilation system
9600 Hourly Maintenance
Check for external damage or peeling paint
Check for water
Cleaning the controller ventilation system
Parts for Fanuc Robot Arc Mate 100iD
Access the parts list for your equipment in MaintainX.
Robot Connection Cable
A05B-2525-J047
Power Cable
A05B-2525-J011
Taper Plug
A97L-0001-0436#1-1D
Seal Washer
A30L-0001-0048#6M
Brake Release Unit
A05B-2450-J350
Robot Connection Cable
A05B-2525-J047
Power Cable
A05B-2525-J011
Taper Plug
A97L-0001-0436#1-1D
Seal Washer
A30L-0001-0048#6M
Brake Release Unit
A05B-2450-J350
Robot Connection Cable
A05B-2525-J047
Power Cable
A05B-2525-J011
Taper Plug
A97L-0001-0436#1-1D
Seal Washer
A30L-0001-0048#6M
Brake Release Unit
A05B-2450-J350
