Cleveland Tablet Counter CT-1000

SWITCH CONFIGURATION & DISASSEMBLY

DISASSEMBLY OF SWITCH ASSEMBLY:

1. Place slotted screwdriver between contactor cartridge and cartridge mounting block as shown in Fig.1.

2. Twist screwdriver to free cartridge.

3. Place screwdriver under tab in the back of the cartridge mounting block as shown in Fig. 3.

4. Twist screwdriver to remove block from the rotary switch.

3. Unscrew locking ring to remove rotary switch.;

NOTE: It is not necessary to remove the valve from the pipeline for repairs.

WARNING: Turn off electrical power supply and depressurize valve before making repairs.

All solenoid valves should be cleaned periodically.

The time between cleanings will vary depending on the medium and service conditions. In general, if the voltage to the coil is correct, sluggish valve operation, excessive noise or leakage will indicate that cleaning is required. Clean valve strainer or filter when cleaning the valve.

1. Keep the medium flowing through the valve as free from dirt and foreign material as possible.

2. While in service, the valve should be operated at least once a month to insure proper opening and closing.

3. Depending on the medium and service conditions, periodic inspection of internal valve parts for damage or excessive wear is recommended. Thoroughly clean all parts.

Warning: This unit is a precision instrument and can be damaged by rough or careless handling.

If the unit is not handled with care, report the issues to the maintenance team and stop the procedure

Enter the current calibration reading

Enter the next recalibration date

Sign off on the chart recorder maintenance

WARNING: Do not use chloride based cleaners or steel wool for cleaning the cook tank.

Prepare a warm solution of water and mild detergent

Clean the inside and outside of the tank using a nylon brush

Remove any grease or dirt build-up from the two probes inside the tank

Clean the baskets and dividers using the same mild detergent

For more difficult cleaning applications, select one of the following

Sign off on the cook tank cleaning

Turn clockwise to relieve tension on spring

While tension is released remove one of the two slotted screws

Insert a pin (approximately 1/8\) in the hole where the first slotted screw was removed from"

While holding Allen wrench remove pin

Turn Allen wrench clockwise to tighten or counter-clockwise to loosen tension to produce desired effect

Re-insert pin in one of the two holes
