Mitsubishi Split-Type, Heat Pump Air Conditioner MXZ-4C36NAHZ
Need answers fast?
Explore the manual using AI.
Turn manuals into instant answers
with your AI-powered assistantTurn manuals into instant answers
with your AI-powered assistant
Manual for Mitsubishi Split-Type, Heat Pump Air Conditioner MXZ-4C36NAHZ
Complete asset maintenance, one click away
Get instant access to all the maintenance information you need. Empower technicians to perform preventive maintenance with asset packages, ready to use right out of the box.
Documents & Manuals
Find all the essential guides in one place.
Tensioning Guide- Belt-diagram
- C-120 pulleys
+ 13 more
Work Order Templates
Pre-built workflows to keep your asset running smoothly.
- Daily Electrical System Inspection
- Replace Roller and Pulley
- Install Engine B-120
+ 29 more
Procedures
Integrate maintenance plans directly into your work orders.
- Motion Industries
- Applied Industrial Technologies
- Electrical Brothers
+ 5 more
Parts
Access the parts list for your equipment in MaintainX.
- Drive Motor
- B2 Rollers
- Tensioning System
+ 40 more
Mitsubishi Split-Type, Heat Pump Air Conditioner MXZ-4C36NAHZ
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Split-Type, Heat Pump Air Conditioner Model MXZ-4C36NAHZ
Integrate maintenance plans directly into your work orders in MaintainX.
Outdoor Unit Refrigirant Charging
Cautions for service
Refrigerant recovered from the unit completely
Refrigerant not released in the air
Cycle charged with specified amount of refrigerant after service
Filter drier installed for service
Filter drier used for new refrigerant
Additional refrigerant charge
Cylinder for R410A is a syphon type
Charging performed with the cylinder of syphon stood vertically
Fan Motor Replacement
(1) Remove the service panel. (See Photo 1)
(2) Remove the top panel. (See Photo 1)
(3) Remove 4 fan grille fixing screws (5 × 12) to detach the fan grille. (See Photo 1)
(4) Remove a nut (for right handed screw of M6) to detach the propeller. (See Photo 2)
(5) Disconnect the connectors, CNF1 and CNF2 on the multi controller circuit board in the electrical parts box.
(6) Remove 4 fan motor fixing screws (5 × 20) to detach the fan motor. (See Photo 3)
Note: Tighten the propeller fan with a torque of 5.7 ± 0.3 N·m. [4.2 ± 0.2 ft = lbs];
Reactor Replacement
Remove the service panel
Upload a photo of the removed service panel
Remove the top panel
Upload a photo of the removed top panel
Remove the electrical parts box
Upload a photo of the removed electrical parts box
Remove 4 screws for reactor (4 x 10) to remove the reactor
Upload a photo of the removed reactor
Sign off on the reactor replacement
TH6 Thermistor Replacement
Upload a photo of the service panel before removal
Service panel removed
Upload a photo of the top panel before removal
Top panel removed
Connector TH7/6 disconnected
Wire clamps loosened
Thermistor <Suction pipe> (TH6) pulled out
Note: When replacing thermistor <Suction pipe> (TH6), replace it together with thermistor <Ambient> (TH7) since they are combined together.
Thermistor <Ambient> (TH7) removed
Bypass Valve Coil And Bypass Valve Replacement
Remove the service panel
Remove the top panel
Remove the cover panel (front)
Remove the cover panel (rear)
Remove the side panel (R)
Remove the bypass valve coil fixing screw (M4 × 6)
Remove the bypass valve coil by sliding the coil upward
Disconnect the connector SV1 (gray) or SV2 (blue) on the multi controller circuit board in the electrical parts box
Remove the electrical parts box
Parts for Mitsubishi Split-Type, Heat Pump Air Conditioner MXZ-4C36NAHZ
Access the parts list for your equipment in MaintainX.
Inverter Starter Type, Hermetic Compressor - 2,8 KW
ANB33FJSMT
Inverter Starter Type, Hermetic Compressor - 2,8 KW
ANB33FJSMT
Inverter Starter Type, Hermetic Compressor - 2,8 KW
ANB33FJSMT
