Mitsubishi Branch Box PAC-MKA51BC
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Branch Box Model PAC-MKA51BC
Integrate maintenance plans directly into your work orders in MaintainX.
LEV Assembly Replacement
Upload Photo 1
Controller cover removed
Under panel removed
Upload Photo 2-1
Insulations and pipe box fixing screws removed
LEV and thermistor connectors disconnected
Lead wires pulled out to the pipe box side
Upload Photo 3
Band cut and rubber mount removed
Thermistor Replacement
Upload Photo 1 of the controller cover and under panel removal
Upload Photo 2-1 of the insulation and pipe box removal
Upload Photo 2-2 of the thermistor removal from sensor holders
Upload Photo of the loosened insulation sheet
Upload Photo of the disconnected connector(s) on the controller board
Upload Photo 2-3 of the lead wire(s) pulled out to the controller board side
Note: Attach the insulation sheet to the thermistor(s) and the lead wire(s) of LEV coil after replacing thermistor(s).
Note: Install the pipe box not to twine the lead wire(s) and the pipe cover around the pipe box.
Sign off on the thermistor replacement
LEV Coil Replacement
Upload Photo 1 of the controller cover and under cover removal
Upload Photo 2-1 of the insulation and pipe cover fixing screws removal
Upload Photo 3 of the LEV coil removal
Insulation sheet which bundles the LEV lead wires loosened
Side clamps loosened and connector(s) on the controller board disconnected
Upload Photo 2-2 or 2-3 of the lead wire(s) pulled out to the pipe box side
Note: Attach the insulation sheet to the thermistor(s) and the lead wire(s) of LEV coil after replacing thermistor(s).
Note: Install the pipe box not to twine the lead wire(s) and the pipe cover around the pipe box.
Sign off on the LEV Coil Replacement
Controller Board Replacement
Remove the controller cover
Upload a photo of the controller cover removed
Loosen the side clamps, then disconnect the connectors on the controller board
Pick an upper edge of the controller board, then pull forward
Upload a photo of the controller board detached
Remove the controller board from the controller board holder
Sign off on the controller board replacement
