Mitsubishi Branch Box PAC-MKA50BC
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Branch Box Model PAC-MKA50BC
Integrate maintenance plans directly into your work orders in MaintainX.
Thermistor Replacement
Upload Photo 1 of the controller cover and under panel removal
Upload Photo 2-1 of the insulation and pipe box removal
Insulations and pipe box removed successfully?
Upload Photo 2-2 of the thermistor removal
Thermistor removed successfully?
Upload Photo 2-3 of the lead wire removal
Lead wire removed successfully?
Note: Attach the insulation sheet to the thermistor(s) and the lead wire(s) of LEV coil after replacing thermistor(s).
Note: Install the pipe box not to twine the lead wire(s) and the pipe cover around the pipe box.
LEV Assembly Replacement
Upload Photo 1 of controller cover and under panel removal
Controller cover removed
Under panel removed
Upload Photo 2-1 of insulation and pipe box fixing screws removal
Insulations removed
Pipe box fixing screws removed
LEV and thermistor connectors disconnected
Lead wires pulled out to the pipe box side
Upload Photo 3 of header assy and LEV assy removal
Controller Board Replacement
Warning: Ensure the machine is powered off before starting the procedure
Upload Photo 1 of the controller cover
Controller cover removed
Side clamps loosened and connectors disconnected
Upload Photo 4 of the controller board
Controller board removed from the holder
Sign off on the controller board replacement
LEV Coil Replacement
Upload a photo of the controller cover before removal
Controller cover removed
Upload a photo of the under cover before removal
Under cover removed
Number of insulations removed
Number of pipe cover fixing screws removed
Upload a photo of the bands before cutting
Bands cut and LEV coil(s) pulled out
Insulation sheet loosened
