Mitsubishi Split-Type, Heat Pump Air Conditioner MXZ-8C60NA-U1
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Split-Type, Heat Pump Air Conditioner Model MXZ-8C60NA-U1
Integrate maintenance plans directly into your work orders in MaintainX.
TH6 Thermistor Replacement
Warning: This procedure requires trained personnel with PPE!
Service panel removed
Upload a photo of the removed service panel
Top panel removed
Upload a photo of the removed top panel
Connectors TH7/6 disconnected
Wire clamps on the back of electrical parts box loosened
Thermistor <Suction pipe> (TH6) pulled out from the sensor holder
Note: When replacing thermistor <Suction pipe> (TH6), replace it together with thermistor <Ambient> (TH7) since they are combined together.
Bypass Valve Coil And Bypass Valve Replacement
Remove the service panel
Remove the top panel
Remove the cover panel (front)
Remove the cover panel (rear)
Remove the side panel (R)
Remove the bypass valve coil fixing screw (M4 × 6)
Remove the bypass valve coil by sliding the coil upward
Disconnect the connector SV1 (gray) on the multi controller circuit board in the electrical parts box
Remove the electrical parts box
Compressor Replacement
Remove the service panel
Remove the top panel
Remove the electrical parts box
Remove the valve bed
Remove the cover panel (front)
Remove the cover panel (rear)
Remove the side panel (R)
Remove front panel fixing screws, 5 (5x12) and 2 (4 x 10) and remove the front panel
Remove 3 separator fixing screws (4 × 10) and remove the separator
Electrical Parts Box Replacement
Upload a photo of the service panel before removal
Service panel removed successfully
Upload a photo of the top panel before removal
Top panel removed successfully
Upload a photo of the connecting wire before disconnection
Connecting wire disconnected successfully
Select all connectors removed from outdoor multi controller circuit board
Disconnected wire pulled out from the electrical parts box successfully
Upload a photo of the terminal cover before removal
4-Way Valve Coil Replacement
Warning: Ensure the power is off before starting the procedure
Upload a photo of the service panel before removal
Service panel removed successfully
4-way valve coil fixing screw removed successfully
4-way valve coil removed successfully
Connector 21S4 disconnected successfully
Sign off on the coil replacement
Parts for Mitsubishi Split-Type, Heat Pump Air Conditioner MXZ-8C60NA-U1
Access the parts list for your equipment in MaintainX.
Inverter Starter Type, Hermetic Compressor - 4,2 KW
ANB66FFZMT
Inverter Starter Type, Hermetic Compressor - 4,2 KW
ANB66FFZMT
Inverter Starter Type, Hermetic Compressor - 4,2 KW
ANB66FFZMT
