Mitsubishi Branch Box PAC-MKA31BC
Create an account to install this asset package.
Maintenance Plans for Mitsubishi Branch Box Model PAC-MKA31BC
Integrate maintenance plans directly into your work orders in MaintainX.
LEV Assembly Replacement
Upload Photo 1
Controller cover removed
Under panel removed
Upload Photo 2-1
Insulations and pipe box fixing screws removed
LEV and thermistor connectors disconnected
Lead wires pulled out to the pipe box side
Upload Photo 3
Band cut and rubber mount removed
Thermistor Replacement
Upload Photo 1 of the controller cover and under panel removal
Upload Photo 2-1 of the insulation and pipe box removal
Thermistors TH-A to E removed from sensor holders?
Upload Photo 2-2 of the thermistor removal
Insulation sheet bundling the thermistor connectors loosened?
Side clamps loosened and connectors on the controller board disconnected?
Lead wires pulled out through the hole to the controller board side?
Upload Photo 2-3 of the lead wires
Note: Attach the insulation sheet to the thermistors and the lead wires of LEV coil after replacing thermistors.
LEV Coil Replacement
Upload a photo of the controller cover before removal
Controller cover removed
Upload a photo of the under cover before removal
Under cover removed
Number of insulations removed
Number of pipe cover fixing screws removed
Upload a photo of the bands before cutting
Bands cut and LEV coil(s) pulled out
Insulation sheet loosened
Controller Board Replacement
Warning: Ensure the machine is powered off before starting the procedure
Upload Photo 1 of the controller cover
Controller cover removed
Side clamps loosened and connectors disconnected
Upload Photo 4 of the controller board
Controller board pulled forward
Controller board removed from the holder
Sign off on the controller board replacement
