Genie Electric Scissors SJIII 4632

WARNING: Ensure platform is fully lowered before winching or towing. Sudden motion could cause the aerial platform to become unstable. Death or serious injury could result.

WARNING: In emergency situations where aerial platform functions are not available and lowering is impeded by an obstacle, utmost care must be taken to move aerial platform far enough to clear the obstacle. In such cases, operation must be extremely smooth with no sudden movements and must not exceed a speed of 2\/sec (50 mm/sec)."

WARNING: When pushing, winching or towing, do not exceed 2 mph (3.2 km/h).

WARNING: Do not push, winch or tow aerial platform onto a slope, or brake the towing vehicle rapidly. Do not pull aerial platform down an incline towards a winch.

Is the aerial platform on level ground?

Are the wheels chocked or blocked to keep aerial platform from rolling?

Is the free-wheeling valve fully opened?

WARNING: The free-wheeling valve must be closed tightly (clockwise) for normal operation.

Are the brakes manually disengaged?

WARNING: To avoid injury, do not operate an aerial platform until all malfunctions have been corrected.

WARNING: To avoid possible injury, ensure aerial platform power is off during your visual and daily maintenance inspections.

CAUTION: Ensure aerial platform is on a firm, level surface.

NOTE: While performing visual and daily inspections in different areas, be aware to also inspect limit switches, electrical and hydraulic components.

Inspect base to platform cables and wiring harness for chafed, corroded and loose wires.

Inspect battery tray wiring harnesses for chafed, corroded and loose wires.

Inspect hydraulic/electrical wiring harnesses for chafed, corroded and loose wires.

Sign off on the electrical components inspection

Ensure mechanisms have no sign of visible damage and are free from dirt and obstructions

Ensure tray latch is secure and in proper working order

Battery Charger (SJIll 3219 - Entrance Side)

Ensure charger is secure and shows no visible damage

Clean battery terminals and cable ends thoroughly with a terminal cleaning tool or wire brush

WARNING: To avoid injury, do not operate an aerial platform until all malfunctions have been corrected.

WARNING: To avoid possible injury, ensure aerial platform power is off during your visual and daily maintenance inspections.

CAUTION: Ensure aerial platform is on a firm, level surface.

NOTE: While performing visual and daily inspections in different areas, be aware to also inspect limit switches, electrical and hydraulic components.

Main Power Disconnect Switch: Turn main power disconnect switch to 'O' off position. Ensure all cables are secure and switch is in proper working condition.

Base Control Switches: Ensure there are no signs of visible damage and all switches are in their neutral positions.

Free-wheeling Valve Knob (SJIll 3219 - Front Side): Ensure there are no loose or missing parts and there is no visible damage.

Brakes: Ensure there are no loose or missing parts and there is no visible damage. Ensure tabs are not locked.

110V Outlet Receptacle: Ensure receptacle is free from dirt and obstructions.

Raise the platform until there is adequate clearance to swing down the maintenance support

Ensure maintenance support is properly secured and shows no visible damage

Ensure scissor assembly shows no visible damage and no signs of deformation in weldments

Ensure all pins are properly secured

Ensure cables and wires are properly routed and shows no signs of wear and/or physical damage

Ensure bumpers are secure and shows no sign of visible damage

Ensure rollers are secure and there is no visible damage

Ensure rollers' path of travel are free from dirt and obstructions

Ensure each lift cylinder is properly secured, there are no loose or missing parts and there is no evidence of damage
