Genie Articulated Boom Lift S-45 TraX

Warning: This procedure requires trained personnel with PPE!

Track assembly cleaned of any dirt, rocks, clay, etc.

Tracks chocked at one end of the machine to prevent rolling

Machine lifted with a jack of ample capacity (20,000 Ibs / 10,000 kg) and supported with jack stands

Visual inspection of the track under the bogey wheels performed

Grease plug on the track tension cylinder loosened

Grease pumped into the grease zerk fitting of the tension cylinder until grease, free from air, comes out of the grease plug

Check oil, fuel, and coolant systems for leaks

Clean/replace air cleaner element

Warning: This test requires trained personnel with PPE!

Push in the platform red Emergency Stop button to the off position

Turn the key switch to ground controls

Pull out the red Emergency Stop button to the on position at the ground controls

From the ground controls, operate each boom function through a partial cycle

From the platform, activate the foot switch and operate each boom function

Pull out the red Emergency stop button to the on position at the platform controls

Activate the foot switch and operate each boom function

Sign off on the ground control override test

Test the Alarm Package (if equipped). Note: The alarms and beacon will operate with the engine running or not running.

Turn the key switch to ground control and pull out the red Emergency Stop button to the on position at both ground and platform controls. Did the alarm sound twice and the flashing beacon turn on and flash?

Activate the boom down function, hold for a moment and then release it. Did the descent alarm sound when the down function is activated?

Turn the key switch to platform controls. Is the flashing beacon on and flashing?

Press down the foot switch. Activate the boom down function, hold for a moment and then release it. Did the descent alarm sound when the down function is activated?

Press down the foot switch. Move the drive control handle off center, hold for a moment and then release it. Move the drive control handle off center in the opposite direction, hold for a moment and then release it. Did the travel alarm sound when the drive control handle is moved off center in either direction?

Sign off on the alarm package test

Required maintenance procedures and additional engine information are available in the manufacturer's manuals. Refer to Specifications, Engine Operator and Maintenance Manuals
