Aerzen Blower GM10S

8.2.1 Maintenance schedule for normal operation

After every 16,000 op. hrs or every 2 years

Chapter 8.3.5 'Changing oil' on page 150

Follow the full oil draining and filling procedure as described in Initial 500 Hours Lube Oil Change

Performing checks after commissioning — After the first 3 operating hours

Check that all components are in place and secure

Re-tighten screws if necessary after cooling down

Is the intake pressure valve operating correctly?

Are the belts in good condition?

Change belts if necessary and establish cause of wear

Loosen the fastening screws and lightly impact the flange cover to loosen the sealing.

Remove the non-return flap from the housing.

Carry out a visual inspection of the non-return flap.

Is the sealing acceptable (no damage or hardening visible)?

Replace the non-return flap if damage or hardening is visible.

Remove dirt, grease, and used sealing agent from the flange surface.

Apply sealing agent to the flange surface of the housing.

8.2.1 Maintenance schedule for normal operation — Weekly

Check for damage and thorough stability

Remove dirt from the belt guard

Is the belt guard fastener tight?

Is there any lubricant bleeding out of the drive motor?

Remove any dirt from the outer belt guard

Is the belt guard sufficiently stable and undamaged?

Maintenance schedule for normal operation

After every 16,000 op. hrs or every 2 years

Chapter 8.3.16 'Checking pipelines for tightness' on page 166

Check flexible pipe connections for tightness

Check flexible pipe connections on the discharge and intake sides for tightness

Is replacement of flexible pipe connections necessary?

Checking intake-side pipelines for tightness

Check pipelines for tightness (visual inspection)
