ThermoFisher Scientific Centrifuge 75002411

Press the large seal in the outer groove of the rotor body (top detail)

Press the small seal into the groove of the rotor collar (bottom detail)

Ensure that the rotor lid closes securely

Is the rotor lid damaged or dulled?

Has the centrifuge reached its 13-year lifetime limit?

Decommission the centrifuge if the lifetime limit is reached.

Rotor, Buckets, and Lids Inspection

Enter the number of cycles for each rotor.

Is the number of cycles within the specified limit for each rotor?

Replace rotors, buckets, and lids if they exceed the specified cycle limit.

Check for damage or wear on accessories

Ensure the level of disinfection is achieved according to requirements

Rinse the centrifuge and all affected accessories with water

Allow the centrifuge and accessories to fully drain and dry

Treat the entire surface of aluminum parts including the cavities with corrosion protection oil (70009824) after disinfecting

Ensure no one is put at risk in case of contamination

Verify that the disinfection method or agent will not damage the equipment

Observe the safety precautions and handling instructions for the disinfection agents used

Use the supplied grease for lubrication

Fill the cavities with approx. 10 ml of carbonated mineral water

Close the rotor as per handling instructions

Shake the rotor vigorously by hand

Did you avoid applying pressure to the lid while shaking?

Ensure all parts are ready for cleaning

Clean rotor, buckets, and accessories outside of the centrifugation chamber

Separate rotor, buckets, lids, tubes, and sealing rings for thorough cleaning

Rinse rotor and accessories with warm water and neutral detergent

Use a soft brush without metal bristles to remove stubborn residue

Rinse rotor and accessories with distilled water

Place rotors on a plastic grate with cavities pointing down to drain and dry
