Thermadyne Industries Flame Cutting Machine VCM-200HS

Remove the bottom cover from the machine

Short out the capacitor by touching an insulated screwdriver to the capacitor terminals

Remove the jam nut and pull the switch inside the case to remove

Verify replacement switch part number

Install the new switch by reversing the removal procedure

Reconnect the switch leads as disconnected in Step 4

Wipe off all parts of the machine, rack, torch and all track surfaces.

Turn the clutch control lever to the FREE position.

Can the machine be easily pushed along the track?

Set the FWD-OFF-REV toggle switch to the OFF position.

Plug the power cord into a 115 V, 60 Hz power outlet.

Adjust the torch holder assembly

Is additional torch clearance needed?

Rotate the torch holder assembly 180° for additional clearance

Tighten all clamping screws to secure the torch position

Short out the capacitor using an insulated screwdriver

Redistribute the grease on the gear train

Redistribute the grease in the groove of the clutch dog

Unplug the power cord before performing any maintenance on the machine.

Short out the capacitor using an insulated screwdriver.

Ensure drive disks and cone are free of grease.

Clean drive disks and cone with a cloth dampened with a solvent that does not leave a residue.

Verify that ball bearings or special bushings are used at all critical locations and require no greasing.
