Quincy Compressor QC02003D1A

Filter Replacement Instructions

Apply a thin film of lubricant to the gasket surface of the new filter

Spin the filter on the threaded stud until the gasket makes contact with the housing

Tighten the filter an additional 3/4 turn

Ensure the filter is not used if bent or damaged

Is the filter compatible with Quin-Cip or QuiCip-D lubricant?

Hydrostatical Air Tank Inspection

Review Fig. 3-13 for recommended air tank inspection intervals

Refer to federal, state, provincial, or local codes for mandatory air tank maintenance information

Tank Wall Thickness Measurement

Measure tank wall thickness at the lowest point where condensation can accumulate

Measure tank wall thickness at various other locations

Is the tank wall thickness within acceptable limits?

Inspect pressure switch contacts

Inspect contact points in motor starter

Lubricate the electric motor following manufacturer’s recommendations

Inspect Equipment for Shipping Damage

Inspect compressor equipment for damage during shipment

If damage is found, describe the damage and actions taken

Demand an inspection from the carrier if damage is found

Record instructions from the carrier on filing a claim for shipping damages

Ensure adequate lifting equipment is available

Follow safety procedures when moving the unit

Verify the compressor model and size from the nameplate

Place a straightedge against the face of the flywheel, touching its rim at two places

Is the belt running parallel to the straightedge?

Adjust the motor pulley so that the belt runs parallel to the straightedge

Use a wheel puller to move the motor pulley on the shaft
