Quincy Compressor 216

Create an account to install this asset package.

Maintenance Plans for Quincy Compressor Model 216

Integrate maintenance plans directly into your work orders in MaintainX.

8 Hourly / 1 Daily Compressor Maintenance

Pre-maintenance Setup

Ensure the compressor is installed in a clean, well-lighted, and adequately ventilated area

Ensure sufficient space is provided around the compressor for inspection, cleaning, and maintenance

Oil Level and Quality Check

Record oil level on bayonet gauge

Is the oil level between high and low marks?

Is the oil discolored or contaminated?

Drain and replace oil if contaminated

System Drainage

Run this procedure

Initial Compressor Inspection

Inspect Compressor Equipment

Inspect compressor equipment for damage during shipment

Was any damage found on the compressor equipment?

Carrier Inspection and Claim

Demand an inspection from the carrier if damage is found

Ask the carrier how to file a claim for shipping damages

Refer to SECTION 3, Freight Damage for complete details

Examine Shipping Containers

Examine every carton and crate upon receipt

Run this procedure

160 Hourly / 1 Monthly Belt Tension Check

Belt Tension Measurement

Measure the span length of the drive (in inches)

Calculate the required deflection (in inches)

Lay a straightedge across the top outer surface of the drive belt from pulley to sheave

Apply pressure with a belt tension gauge and record the deflection force reading

Is the deflection force reading within the minimum and maximum values?

Adjust the belt(s) if the deflection force reading is not within the specified range

New Belt Tension Adjustment

Calculate the maximum deflection force value plus 33%

Run this procedure

1 Daily Air Tank Draining

Preparation

Disconnect & lockout the compressor from the power source (electric models) or disconnect the spark plug wire from the spark plug (gas engine models).

Is the compressor stored in a heated area if subjected to freezing temperatures?

Pressure Reduction

Enter the current air pressure in the tank (PSIG)

Is the air pressure in the tank 30 PSIG or less?

Draining Process

Open the drain valve to allow the moisture and air mixture to drain from the tank.

Close the drain valve once the moisture has been completely drained.

Run this procedure

Initial 50 Hours Belt Tension Check

Measure Span Length and Deflection

Measure the span length of the drive (in inches)

Calculate the required deflection (in inches) by multiplying the span length by 0.016
