Maintenance Plans for Mori Seiki CNC Vertical Machining Center Model MV-65/40

Integrate maintenance plans directly into your work orders in MaintainX.

Hydraulic/Pneumatic System Air Bleeding

Check mark

Initial Setup

Check mark

Move the arm to the home position and set it in the tool unclamp/clamp state.

Check mark

Select the automatic mode.

Check mark

Apply 0.4 MPa (56.88 psi) pressure to the charge tank.

Check mark

Air Bleeding Process

Check mark

Open and close air bleeder valves in order

Check mark

Pressure Check

Check mark

Carry out unclamping in the manual mode.

Check mark

Read the pressure gauge. It should indicate 4.8-5.7 MPa (696.78-824.76 psi). [MV-65/40: 3.4-3.6 MPa (497.7-526.1 psi)]

Run this procedureArrow right

Lubrication Oil Handling and Maintenance

Check mark

Storage

Check mark

Store the lubricating oil away from rain and direct sunlight.

Check mark

Ensure no contact with dirt and water during storage.

Check mark

Confirm that no degraded oils or oils mixed with foreign matter are used.

Check mark

Oil Jugs and Intermediate Tanks

Check mark

Ensure different oil jugs are used for different lubricating oils and coolant.

Check mark

Inspect and clean the intermediate tank periodically to remove dirt and water.

Check mark

Slideway Lubrication Unit

Check mark

Clean the inside of the slideway lubrication unit tank at least once a year.

Run this procedureArrow right

Air Supply Check

Check mark

Air Quality Check

Check mark

Is the compressed air clean and dry?

Check mark

Air Pressure Check

Check mark

Enter the air pressure from the FRL unit air regulator pressure gage

Check mark

Is the air pressure at 0.5 MPa (71.1 psi)?

Check mark

Enter the charge tank pressure

Check mark

Is the charge tank pressure at 0.2 MPa (28.44 psi)?

Check mark

Air Supply Volume Check

Check mark

Enter the air supply volume in L/min (ANR)

Run this procedureArrow right

Air Filter Lubrication

Check mark

Initial Inspection

Check mark

Ensure the air filter is disconnected from the air supply

Check mark

Inspect the air filter for visible damage or wear

Check mark

Lubrication Process

Check mark

Apply lubricant to the float mechanism

Check mark

Lubricate the piston and spring assembly

Check mark

Ensure the O-ring is properly lubricated

Check mark

Reassembly and Testing

Check mark

Reassemble the air filter components

Run this procedureArrow right

Hard-Limit Adjustment

Check mark

Positive Direction Adjustment

Check mark

Set +OT (soft-limit) for the axis to 5000 (5 mm)

Check mark

Feed the axis to the soft-limit position

Check mark

Adjust the position of the dog

Check mark

Negative Direction Adjustment

Check mark

Set -OT (soft-limit) for the axis to (axis travel + 5 mm) with a minus sign

Check mark

Feed the axis to the soft-limit position

Check mark

Adjust the dog position

Check mark

Finalization

Run this procedureArrow right
