Daikin Outdoor Unit Cooling Only Air Conditioner RKM71PVMG

Warning: Wait for 10 minutes or more after turning off all power supplies before disassembling work.

Remove the 2 lower screws first.

Ensure the wire harness is facing downward when reassembling.

Has the power supply been turned off for at least 10 minutes?

Remove the sound blanket (top upper)

Remove the screw and slightly push the partition plate (1) to the left for easy work

Remove the sound blanket (outer)

Remove the sound blanket (top lower)

Remove the sound blanket (inner)

Warning: Be sure to wait for 10 minutes or more after turning off all power supplies before disassembling work.

Remove the cover of the electrical box by releasing the 4 hooks indicated by W.

Service Monitor PCB Disconnection

Disconnect the connectors from the service monitor PCB

Detach the 4 clamps with pliers and remove the service monitor PCB.

Terminal Board and Ground Wire Removal

Remove the screws of the terminal board and the earth / ground wire.

Unfasten the hook on the right.

Warning: Wait for 10 minutes or more after turning off all power supplies before disassembling work.

Pull out the electronic expansion valve coil.

Remove the screw and remove the four way valve coil.

Cooling only models have no four way valve coil.

Pull out the outdoor heat exchanger thermistor.

Be careful not to lose the clip for the thermistor.

Slightly open the sound blanket (outer).

Remove the sound blanket (top upper).

The design of the sound blankets varies depending on the model.

Warning: Wait for 10 minutes after turning off all power supplies before disassembling work.

Lift the top panel and remove it.
