Daikin Outdoor Unit Cooling Only Air Conditioner RKV71NVMV

Has it been 10 minutes since all power supplies were turned off?

Open the sound blanket (outer).

Remove the sound blanket (top upper).

Remove the screw and slightly push the partition plate (1) to the left for easy work.

Remove the sound blanket (outer).

Remove the sound blanket (top lower).

Remove the sound blanket (inner).

Ensure all power supplies are turned off and wait for 10 minutes before starting disassembly

Lift the top panel and remove it

Warning: Wait for 10 minutes or more after turning off all power supplies before disassembling work.

Remove electronic expansion valve coil

Remove screw and four way valve coil

Pull out outdoor heat exchanger thermistor

Slightly open the sound blanket (outer)

Remove the sound blanket (top upper)

Remove discharge pipe thermistor

Wait for 10 minutes after turning off all power supplies before starting disassembly

Remove the 2 lower screws first

Ensure the wire harness is facing downward during reassembly

Wait for 10 minutes after turning off all power supplies before starting disassembly.

Ensure no contact with heated pipes and parts from the gas brazing machine.

Is the area ventilated in case of refrigerant gas leakage?

Prepare wet cloth to extinguish fire in case refrigerant oil catches fire.

Collect all refrigerant gas to prevent atmospheric discharge.

Restore piping using non-oxidation brazing.
