Genie Articulated Boom Lift Z-135/70

- Test the Emergency Power System (excludes ALC-600 and ALC-1000 Models)

1. Turn the key switch to ground control and pull out the red Emergency Stop button to the on position at both the ground and platform controls

2. At the ground controls, break the security tie and lift the emergency power switch cover (if equipped)

3. Simultaneously hold the emergency power switch on and operate each boom function through a partial cycle

• Result: All boom functions operate

4. Close the emergency power switch cover and secure the cover with a security tie (if equipped)

5 Turn the key switch to platform controls

6. At the platform controls, break the security tie and lift the emergency power switch cover (if equipped). 7. Press down on the foot switch and simultaneously hold the emergency power switch on and operate each boom function through a partial cycle

• Result: All boom functions operate

- Clean/replace air cleaner element

- Replace engine oil and filter

- Check Fan belt tension and damage

- Check Battery electrolyte level

- Clean Air cleaner element (Replace the element after 6 times cleaning)

- Clean Fuel filter (element type)

- Replace Oil filter cartridge, Z482

- Check for leaks Oil, fuel and coolant systems

- Replace engine oil and filter

- Clean/replace air cleaner element

- Check electrical wiring for chafing or damage

- Check fan belt tension and damage

- Check radiator hoses and clamps

- Check intake manifold for vacuum leaks

- Check radiator hoses and clamps

- Replace engine oil and filter
