Allen Bradley AC Drive PowerFlex 523
Create an account to install this asset package.
Maintenance Plans for Allen Bradley AC Drive Model PowerFlex 523
Integrate maintenance plans directly into your work orders in MaintainX.
Bus Capacitor Maintenance
Reforming Voltage Requirements
Set reforming voltage to 1.35…1.45 times the rated AC system voltage
Power Supply Current Monitoring
Measure the power supply current draw
Is the power supply current draw within the acceptable range (≤ 500 mA)?
Preparation for PowerFlex 753 and 755 Drives
Disconnect internal stirring fans for specific drive frames
Operating Mechanism Maintenance
Inspection and Replacement
Check for proper functioning and freedom from sticking or binding
Replace any broken, deformed, or badly worn parts or assemblies
Check and securely re-tighten any loose fasteners
Lubrication
Is lubrication specified for this product?
Lubricate per individual product instructions
Are there any Allen-Bradley® magnetic starters, contactors, or relays?
Ensure no lubrication is applied to Allen-Bradley® devices
Unlock efficiency
with MaintainX CoPilot
MaintainX CoPilot is your expert colleague, on call 24/7, helping your team find the answers they need to keep equipment running.
