Advance Cleaning Equipment AQUAMATIC SE

Remove the Belt Guard from the left side of the machine.

Loosen the brush drive motor mount and slip the Belt off the motor pulley.

Pry the Belt Cover off the Brush Housing.

Pull the pulley end of the brush out of the Brush Housing.

Inspect the Belt for wear or damage, replace if necessary.

Inspect vacuum motor carbon brushes for wear

Is the vacuum motor brush service up to date?

Wheel Drive Motor Brushes Check

Inspect wheel drive motor carbon brushes for wear

Is the wheel drive motor brush service up to date?

Acknowledge the importance of servicing carbon brushes to avoid motor damage not covered under warranty

Pump grease into the grease fitting on the caster wheel until it seeps out around the bearing.

Wipe off the excess grease to avoid staining carpet.

Clean the Vacuum Exhaust Filter

Remove the foam filters from the bottom of the machine.

Wash the foam filters in warm water.

Have the filters dried completely before putting them back into the machine?

Remove built-up string, hair, or carpet fibers from the brush

Check the bristle length in inches

Are the brush bristles worn to 1/4 inch (6 mm) or less?

Change the brush if bristles are worn to 1/4 inch (6 mm)

Remove built-up string, hair, or carpet fibers from the pick-up tool

Remove the spray nozzle from under the machine
