Zebra Printer R110Xi

Warning: Turn the AC power switch off (O) and remove the power cord before performing this procedure.

The printer uses a metric-style fuse (5 × 20 mm IEC) rated at F5A, 250 V.

The AC power entry module comes with two approved fuses in the fuse holder: one is in-circuit, and the second is provided as a spare.

The end caps of the fuse must bear the certification mark of a known international safety organization.

Use a small-blade screwdriver or similar tool to remove the fuse holder.

Remove the faulty fuse and install a new fuse in the in-circuit position.

Important: If you use the spare fuse, be sure to order a replacement fuse from an authorized Zebra distributor. The spare fuse should be the exact type and rating as the original in-circuit fuse.

Snap the fuse holder back into the AC power entry module.

Reconnect the power cord, and turn the printer on (I).

Warning: Use solvent for cleaning!

CLEAN HEAD NOW message appears?

Enter the length of labels used in Direct Thermal Print Mode

Enter the length of ribbon used in Thermal Transfer Print Mode

Sign off on the media path cleaning

Clean the snap plate when label adhesive or a label is stuck to the underside.

The type of snap plate in your printer will depend on whether the printer is standard or RFID-ready/enabled. Figure 27 shows the snap plate in a standard non-RFID printer.

To clean the snap plate in a standard printer, complete these steps:

1. Insert a small-blade screwdriver or similar tool into the loop on the left side of the snap plate.

2. Gently lift the left side of the snap plate.

3. Insert a small-blade screwdriver or similar tool into the loop on the right side of the snap plate.

4. Gently lift the right side of the snap plate.

5. Remove the snap plate from the printer.

Warning: Ensure the machine is turned off before starting the cleaning process

CLEAN HEAD NOW message appears?

Sign off on the sensor cleaning

Warning: Ensure the printer is turned off and unplugged before cleaning.

CLEAN HEAD NOW message appears?

Direct Thermal Print Mode: Have you used every roll of labels or 500 ft (150 m) of fanfold labels?

Thermal Transfer Print Mode: Have you used every roll (1500 ft or 450 m) of ribbon?

Upload a photo of the cleaned ribbon path

Sign off on the ribbon path cleaning
