Zebra Printer 110XiIIIPlus

Warning: The cutter blade is sharp. Do not touch or rub the blade with your fingers.

Clean the stationary cutter blade with a swab and solvent

Is the cutter clean and free of label fragments and adhesive?

If cleaning does not remove label fragments and adhesive, contact an authorized service technician.

Sign off on the cutter cleaning

Warning: Turn the AC power switch off (O) and remove the power cord before performing this procedure.

The printer uses a metric-style fuse (5 × 20 mm IEC) rated at F5A, 250 V.

The AC power entry module comes with two approved fuses in the fuse holder: one is in-circuit, and the second is provided as a spare.

The end caps of the fuse must bear the certification mark of a known international safety organization.

Use a small-blade screwdriver or similar tool to remove the fuse holder.

Remove the faulty fuse and install a new fuse in the in-circuit position.

Important: If you use the spare fuse, be sure to order a replacement fuse from an authorized Zebra distributor. The spare fuse should be the exact type and rating as the original in-circuit fuse.

Snap the fuse holder back into the AC power entry module.

Reconnect the power cord, and turn the printer on (I).

Warning: Ensure the printer is turned off and unplugged before cleaning.

CLEAN HEAD NOW message appears?

Direct Thermal Print Mode: Have you used every roll of labels or 500 ft (150 m) of fanfold labels?

Thermal Transfer Print Mode: Have you used every roll (1500 ft or 450 m) of ribbon?

Upload a photo of the cleaned ribbon path

Sign off on the ribbon path cleaning

Perform these procedures at the following times:

• Direct Thermal Print Mode: After every roll of labels or 500 ft (150 m) of fanfold labels.

• Thermal Transfer Print Mode: After every roll (1500 ft or 450 m) of ribbon.

Perform these procedures at the following times:

• Direct Thermal Print Mode: After every roll of labels or 500 ft (150 m) of fanfold labels.

• Thermal Transfer Print Mode: After every roll (1500 ft or 450 m) of ribbon.
