TimberPro Forwarder TF630B

Warning: Only use approved track chains for the TF 830 and TB 630 machines.

Follow the track chain manufactures instructions when installing and tensioning track chains.

Track chains installed correctly?

Track chains tensioned correctly?

Sign off on the track chains maintenance

Warning: This procedure requires trained personnel with PPE!

Enter the current hour meter reading

Upload a photo of the dipstick reading

Is the oil level at the top mark on the dipstick?

Is addition of SAE 75W-90 synthetic transmission oil required?

Sign off on the gearbox oil level check

Warning: This procedure requires trained personnel with PPE!

Notice: The wheel mounting studs on the N.A.F. bogie axle serve two purposes; (1) retain the wheel/tire to the axle, and (2) retain the planetary wheel drive to the axle hub casting.

If the wheel/tire assembly is allowed to work loose a failure of the wheel planetary and axle hub will occur.

It is very important that the wheel lug nuts be kept tight. The machine operator should be aware of the importance of the wheel lug nuts being kept tight.

Enter the torque applied to the wheel lug nuts

Did the wheel lug nuts reach the required torque of 600 ft.lbs. (800 Nm)?

Upload a photo of the torqued wheel lug nuts

Sign off on the wheel lug nuts torque

Warning: Use a Good Quality grease containing at least 5-6% Molybdenum by volume. Lubriplate #176 is recommended.

Clean the areas around the grease nipples and output plugs

Remove the white plastic caps and open at first one output screw plug

Start the refill at both grease nipples for two sections per half-circle, with standard grease

Lubricate with hand grease gun until grease squeezes out with thumb width from the output opening for every lubricating process

Clean this output and close the opening with screw plug and plastic cap

Open the opposite output plug and repeat the procedure on the other half-circle

Sign off on the lubrication process

Warning: This procedure should be performed by trained personnel only.

Upload a photo of the level sight glass

Enter the oil level in the sight glass

Check for signs of contamination in the drained oil
